ITC-FT25601-A1 Board-Level Burning & FCT Tester
Product Overview
PCBA products. Electrical testing: voltage, current, power. Communication: CAN, CANFD, LIN, Ethernet. Functions: IO signals, video, audio, RF, data read/write. Programming: MCU, SOC flashing.
Technical Specifications
| Parameter | Value |
|---|---|
| DUT Dimension | 250*350mm (Customizable) |
| Overall Dimension | D*W*H=1200mm*1800mm*2600mm |
| Color | Off‑white |
| Material | Sheet metal + Bakelite + Acrylic |
| Operation Height | 950mm, 1550mm |
| Fixture | Double‑sided pin‑press fixture & product connector mating |
| Operation Mode | Drawer‑type, robotic arm for upstream‑downstream material handling |
| Cycle Time (CT) | 50s~300s (Depends on product test conditions) |
